TracoPower TMR 3-0513WISM DC/DC converter (SMD) 200 mA 3 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 22.68
3
4% = € 0.98
€ 21.70
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 22.68 / piece)
€
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
TMR 3WISM
- Min. input voltage
4.5 V DC
- Input voltage (max.)
12 V DC
- No. of outputs
1 x
- Max. output current
200 mA
- Output current (max.) - rounded
200 mA
- Efficiency (max.)
84 %
3 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 19 x 15.40 x 8.70 mm
- Height
8.70 mm
- Length
19 mm
- Width
15.40 mm
- RoHS-compliant
Yes
- Output voltage (max.)
15.0 V DC
- Output voltage (min.)
15.0 V DC
- Weight
3.50 g
- Content
1 pc(s)
