TracoPower TRI 15-2422 DC/DC converter (print) 625 mA 15 W No. of outputs: 2 x Content 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Minimum order quantity: 10
Total (€ 81.99 / piece)
€ 81.99
incl. VAT
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TRI 15-2422
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Max. output current
625 mA
- Output current (max.) - rounded
625 mA
- Efficiency (max.)
90 %
15 W
- Insulation voltage
4200 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 50.80 x 25.40 x 12 mm
- Height
12 mm
- Length
50.80 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Output voltage (max.)
12 V DC
-12 V DC
- Output voltage (min.)
12 V DC
-12 V DC
- Weight
30 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3372367 TracoPower TRI 15-2422 DC/DC converter (print) 625 mA 15 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3372367 TracoPower TRI 15-2422 DC/DC converter (print) 625 mA 15 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3372367 TracoPower TRI 15-2422 DC/DC converter (print) 625 mA 15 W No. of outputs: 2 x Content 1 pc(s)
