TracoPower TRN 3-2421SM DC/DC converter (SMD) 300 mA 3 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 24.36
3
4% = € 1.06
€ 23.30
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 24.36 / piece)
€
Only 7 Piece(s) available
Technical specifications
- Type
TRN 3SM
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Max. output current
300 mA
- Output current (max.) - rounded
300 mA
- Efficiency (max.)
79 %
3 W
- Insulation voltage
1600 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 11.90 x 11.30 x 7.60 mm
- Height
7.60 mm
- Length
11.90 mm
- Width
11.30 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- Output voltage (max.)
5 V DC
-5 V DC
- Output voltage (min.)
5 V DC
-5 V DC
- Weight
2.10 g
- Product type
DC/DC converter (SMD)
