TracoPower TSR 0.6-4833WI DC/DC converter (print) 600 mA 5 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 10.92
3
6% = € 0.61
€ 10.31
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 10.92 / piece)
€ 10.92
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
TSR 0.6-4833WI
- Min. input voltage
9 V DC
- Input voltage (max.)
72 V DC
- No. of outputs
1 x
- Max. output current
600 mA
- Output current (max.) - rounded
600 mA
- Efficiency (max.)
85 %
5 W
- Connection
Solder pins
- PSU features
DC-to-DC converter
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 12.0 x 8.6 x 13.4 mm
- Height
13.4 mm
- Length
12.0 mm
- Width
8.6 mm
- RoHS-compliant
Yes
- Output voltage (max.)
3.3 V DC
- Output voltage (min.)
3.3 V DC
- Weight
3 g
- Content
1 pc(s)
