Turck U7901-05 Sensor/actuator connector (pre-fab) M12 0.5 m No. of pins (RJ): 8 1 pc(s)
Product type
Sensor/actuator connector (pre-fab)
Connector standard
Ethernet
Connection side A
M12 plug, straight
No. of pins
8
Cable length
0.5 m
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Type
RSS RSS 841-0.5M
- Product type
Sensor/actuator connector (pre-fab)
- Connector standard
Ethernet
- Connection side A
M12 plug, straight
- No. of pins
8
- Cable length
0.5 m
- Jacket material
TPE
- Nominal voltage
48 V
- Nominal current
2 A
- Nominal current - rounded value
2 A
- Outside Ø
7.7 mm
- Thread type connection side
M12
- Thread type (wiring and installation)
M12
- Contact surface
Gold
IP67
- Features
Shielded
- Min. temperature
-40 °C
- Max. temperature
80 °C
- Manufacturer part #
U7901-05
- Content
1 pc(s)
- Cable Ø
7.7 mm
- RoHS-compliant
Yes
48 V
Pin
Plastic
-40-80 °C
Gold
3
Straight
IP67
2 A
- UKCA
not relevant
