UBC Bearing NKXR 17 Z Cylindrical roller bearing Bore diameter 17 mm Outside diameter 31.2 mm Rotational speed (max.) 84
Product type
Cylindrical roller bearing
Outside Ø
31.2 mm
Bore Ø
17 mm
Type
NKXR 17 Z
Manufacturer part #
NKXR 17 Z
EAN:
Part number:
Item no:
Number
Total (€ 21.99 / piece)
€ 21.99
incl. VAT
Only 4 Piece(s) available
Technical specifications
- Type
NKXR 17 Z
- Product type
Cylindrical roller bearing
- Manufacturer part #
NKXR 17 Z
- Type (ball bearings)
NKXR
- Outside Ø
31.2 mm
- Bore Ø
17 mm
- Dynamic load rating (axial)
15900 N
- Dynamic load rating (radial)
13500 N
- Static load rating (axial)
33500 N
- Radial load rating
15000 N
- Rotational speed (max.)
8400 U/min
- Features
Unilateral
- Dimensions
(dw/Fw x D2 x D x C x C1 x C2) 17 x 31,2 x 26 x 25 x 9 x 8 mm
- Dim
(dw/Fw x D2 x D x C x C1 x C2) 17 x 31,2 x 26 x 25 x 9 x 8 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 199906 UBC Bearing NKXR 17 Z Cylindrical roller bearing Bore diameter 17 mm Outside diameter 31.2 mm Rotational speed (max.) 84
Description
Cylindrical roller bearings consist of a robust outer race, inner race, rollers and a cage. Outer races either feature bilateral collars, or no collar at all. Inner races come in different types:
Single-row:
· N = two collars on inner race, no collar on outer race
· NU = no collars on inner race
· NJ = one collar on inner race
· NUP = inner race with 1 collar, 1 free-moving separator
Double-row:
· NN = double row cylindrical roller bearing
· NNU = double row cylindrical roller bearing
The cage prevents the moving rollers touching each other. Cylindrical roller bearings are extremely robust, able to cope with high radial load. Moreover, the cage enables movement at high speed. The bearings can be dissaasembled which makes both fitting and taking them out easier. This also enables optimum fitting of inner and outer race.
Postposed characters are used to identify different bearing types.
· C3, C4 = clearance rating
· E = reinforced
· EX = reinforced
· M1 = two-part brass cage, roller guidance
· M1A = guidance on outer ring
· TVP2 = robust PVC cage
· JP3 = sheet metal cage
Single-row:
· N = two collars on inner race, no collar on outer race
· NU = no collars on inner race
· NJ = one collar on inner race
· NUP = inner race with 1 collar, 1 free-moving separator
Double-row:
· NN = double row cylindrical roller bearing
· NNU = double row cylindrical roller bearing
The cage prevents the moving rollers touching each other. Cylindrical roller bearings are extremely robust, able to cope with high radial load. Moreover, the cage enables movement at high speed. The bearings can be dissaasembled which makes both fitting and taking them out easier. This also enables optimum fitting of inner and outer race.
Postposed characters are used to identify different bearing types.
· C3, C4 = clearance rating
· E = reinforced
· EX = reinforced
· M1 = two-part brass cage, roller guidance
· M1A = guidance on outer ring
· TVP2 = robust PVC cage
· JP3 = sheet metal cage
