Technical specifications
- Conductor material: Copper
- Conductor class: Single-wire
- Wire identification: Colour
- With ground wire: Yes
- Max. Load Conductor temperature 70 °C
- Side wire: No.
- Jacket material: Polyvinyl chloride (PVC)
- Fire classification to EN 13501-6: ECA
- Min Permitted bending radius, stationary use/fixed installation: 275 mm
- Conductor shape: Round
- Lead jacket: No.
- Concentric conductor: Without
- Product type
Power feed
- Cable type
NYY-J
- No. of leads
5 x
- Cross section (each core)
6 mm²
- No. of leads (part 2)
5 x
- Cross section (each core) (part 2)
6 mm²
- Cross section
5 x 6 mm² + 5 x 6 mm²
- Cable features
Flat
Flexible
- Outside Ø
18.30 mm
- Factory colour
Black
- Content
50 m
- Nominal voltage
1000 V
- Nominal voltage U0
600 V
- Packaged
Yes
- Sold per metre
No
- Manufacturer part #
VER NYY-J 5x 6 RE Eca Ri.50
- Insulation material
Polyvinyl chloride
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (flexible installation)
70 °C
- Min. temperature range (fixed installation)
-30 °C
- Max. temperature range (fixed installation)
70 °C
- Max. length sold by the metre
50 m
- Type
VER NYY-J 5x 6 RE Eca Ri.50
- Shielded
No
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3336761 VER NYY-J 5x 6 RE Eca Ri.50 Power feed NYY-J 5 x 6 mm² Black 50 m
Description
Power supply cables for outdoor, earth, water, indoor, cable, for power stations, industry and switchgear as well as in local networks if mechanical damage is not to be expected. Max. operating temperature: 70 °C
