Visaton F 8 SC - 8 Ohm 3.3 inch 8 cm Wideband speaker 20 W 8 Ω Magnetic shielding

A black speaker with a round membrane cone and metal frame, photographed from a slightly elevated angle.
Technical drawing of a round speaker with dimensions: diameter 58 mm, total depth 42 mm. Side and top views shown.
1/2
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 5 Nov
41 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 16.99 / piece)
€ 16.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Visaton F8 SC broadband loudspeaker

  • Particularly suitable for small multimedia speakers

Technical specifications

Product type

Wideband speaker

Features

Magnetic shielding

Speaker size (cm)

8 cm

Speaker size (inch)

3.3 inch

RMS capacity

20 W

Max. load

30 W

Max. frequency

15000 Hz

Min. frequency

80 Hz

Impedance

8 Ω

Recess diameter

76 mm

Recess depth

42 mm

Weight

250 g

Frequency range

80 Hz - 15000 Hz

Documents & Downloads

Datasheet

Datasheet 311682 Visaton F 8 SC - 8 Ohm 3.3 inch 8 cm Wideband speaker 20 W 8 Ω Magnetic shielding

User & Safety Instructions

User & Safety Instructions 311682 Visaton F 8 SC - 8 Ohm 3.3 inch 8 cm Wideband speaker 20 W 8 Ω Magnetic shielding

Description

8 cm (3.3") broadband loudspeaker. Magnetically shielded
