Name: VOLTCRAFT VRLA charger BC800 6 V, 12 V Charging current (max.) 0.8 A
Brand: VOLTCRAFT
SKU: 2867717
Availability: InStock

A battery charger with a mains cable and two crocodile clips, one red and one black, for connecting to battery terminals.

Black power supply with European plug and thin, long cable with small, round connector. Suitable for standard chargers.<br><br>Note: The translation is already in British English and maintains the original meaning and formatting.

'A car battery with connected terminals is being charged via a charger plugged into a power socket.'

1/4

Our service for you

Fast track dispatch on Wed 14 Oct

1011 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 14.99 / piece)

€ 14.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Lead acid battery charger; 6V/ 12V

For 6 V/ 12 V lead-acid batteries
Wide range input (100 - 240 V)

Technical specifications

recommended battery capacity (min.): 1Ah (6V) or 1.2Ah (12V)
recommended battery capacity (max.): 8Ah (6V or 12V)
Charge voltage: 7.2V for 6V battery, 14.6V for 12V battery
Cable length: 1.2 meter

Product type: VRLA charger

Matching rechargeable battery: SLA
Lead-acid
Lead acid membrane

Suitable for lead-type rechargeables: 6 V
12 V

Recommended battery capacity (min.): 1 Ah

Recommended battery capacity (max.): 8 Ah

Charging slots: 1

Operating voltage: 100 - 240 V / AC

Charging current (max.): 0.8 A

Charging current at 6 V: 0.8 A

Charging current at 12 V: 0.8 A

Length: 74.3 mm

Width: 78.7 mm

Height: 28.6 mm

Weight: 107 g

Dim: (L x W x H) 74.3 x 78.7 x 28.6 mm

Plastic free packaging: Plastic-free packaging

Compliance & Certifications

Certified by EU Garan

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2867717 VOLTCRAFT VRLA charger BC800 6 V, 12 V Charging current (max.) 0.8 A

Warranty Terms

Warranty Terms 2867717 VOLTCRAFT VRLA charger BC800 6 V, 12 V Charging current (max.) 0.8 A

Description

Uncomplicated charging of lead-acid batteries
For all lead-acid batteries with 6 or 12 V voltage, the "lead-acid battery charger BC800 6V/12V" enables easy, uncomplicated charging. Simply connect black and red clip to the battery, observe correct polarity and plug the charger into a socket.

Charging status-display via LED
The red LED is lit during charging and the completed process is indicated by flashing. If the battery is defective or incorrect polarity, the LED remains off. Short-circuit and polarity reversal protection offer additional security.

This text is machine translated.

Features

With LED indicator
Red LED on (charging), Flashing red LED (charging complete), LED off (bad cell or incorrect polarity).
Short circuit protection
Reverse connection protection

Scope of delivery

Main unit
2.5 x 5.5 mm detachable plug
cable with black & red clamp
User manual

Description

Features

With LED indicator
Red LED on (charging), Flashing red LED (charging complete), LED off (bad cell or incorrect polarity).
Short circuit protection
Reverse connection protection
