WAGO 243-211 Screw terminal flexible: - fixed: 0.28-0.5 mm² Number of pins: 8 500 pc(s) Dark grey, Red
Product type
Screw terminal
Cross section (inflexible) (min.)
0.28 mm²
Cross section (inflexible) (max.)
0.5 mm²
Number of pins
8
Series
243
Datasheet (PDF)
EAN:
Part number:
Item no:
Number (Package size 500 pc(s))
Total (€ 1.05 / piece)
€ 525.00
incl. VAT
14-day return policy included
Highlights & Details
Connector
- 243-211
- Industrial packaging with 500 pieces
Technical specifications
- BUS INTERF.CONN.BLOCK 2P. D.GREY/RED
- Product type
Screw terminal
- Cross section (inflexible) (min.)
0.28 mm²
- Cross section (inflexible) (max.)
0.5 mm²
- Number of pins
8
- Factory colour
Dark grey
Red
- Series
243
- Nominal current
6 A
- Nominal current - rounded value
6 A
- Content
500 pc(s)
- Manufacturer part #
243-211
24 - 22
- Stripping length
5 - 6 mm
- Connection
Quick-connect
- Industrial packaging
Yes
- Insulation material
PA 6.6
- Contact material
Copper alloy
- Nominal voltage
150 V
- Width
10 mm
- Connector clip features
Test window
Documents & Downloads
Datasheet
Datasheet 729764 WAGO 243-211 Screw terminal flexible: - fixed: 0.28-0.5 mm² Number of pins: 8 500 pc(s) Dark grey, Red
User & Safety Instructions
User & Safety Instructions 729764 WAGO 243-211 Screw terminal flexible: - fixed: 0.28-0.5 mm² Number of pins: 8 500 pc(s) Dark grey, Red
Description
For EIB applications, dark gray and red can be locked.
This text is machine translated.
This text is machine translated.
What kind of Connector Clips & Single Wire Connectors are you looking for?
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
