WAGO 243-212 Screw terminal flexible: - fixed: 0.28-0.5 mm² Number of pins: 8 500 pc(s) Light grey, Yellow
Product type
Screw terminal
Cross section (inflexible) (min.)
0.28 mm²
Cross section (inflexible) (max.)
0.5 mm²
Number of pins
8
Series
243
Datasheet (PDF)
EAN:
Part number:
Item no:
Number (Package size 500 pc(s))
Total (€ 1.05 / piece)
€ 525.00
incl. VAT
14-day return policy included
Highlights & Details
Connector
- 243-212
- Industrial packaging with 500 pieces
Technical specifications
- BUS COUPLER CONN-GREY/YEL
- Product type
Screw terminal
- Cross section (inflexible) (min.)
0.28 mm²
- Cross section (inflexible) (max.)
0.5 mm²
- Number of pins
8
- Factory colour
Light grey
Yellow
- Series
243
- Nominal current
6 A
- Nominal current - rounded value
6 A
- Content
500 pc(s)
- Manufacturer part #
243-212
24 - 22
- Stripping length
5 - 6 mm
- Connection
Quick-connect
- Industrial packaging
Yes
- Insulation material
PA 6.6
- Contact material
Copper alloy
- Nominal voltage
150 V
- Width
10 mm
- Connector clip features
Test window
Documents & Downloads
Datasheet
Datasheet 729765 WAGO 243-212 Screw terminal flexible: - fixed: 0.28-0.5 mm² Number of pins: 8 500 pc(s) Light grey, Yellow
User & Safety Instructions
User & Safety Instructions 729765 WAGO 243-212 Screw terminal flexible: - fixed: 0.28-0.5 mm² Number of pins: 8 500 pc(s) Light grey, Yellow
Description
For EIB applications, light gray and yellow can be locked.
