WAGO EPSITRON® 787-1675 787-1675 Industrial UPS

EAN:
Part number:
Item no:
Industrial control device with multiple ports and status LEDs, standing vertically and showing connection options for power and data.
Datasheet (PDF)
Fast track dispatch on Tue 27 Oct
16 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 565.00 / piece)
€ 565.00
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Primär getaktete Stromversorung mit integrierter USV-Lade- und Kontrolleinheit EPSITRON®

  • DC 23 V - 28.5 V (mains-operated)
  • DC 18.5 V - 27.5 V (battery operation)
  • LED status indicator

Technical specifications

  • CLASSIC-NETZGERÄT M.USV 230 / 24V 5A
Input voltage

20.4 - 25.5 V DC

Product type

Industrial UPS

No. of outputs

2 x

Output

RS232

Input voltage (max.)

240 V AC

Min. input voltage

100 V AC

Output voltage (max.)

24 V DC

Output voltage (min.)

24 V DC

Dim

(W x H x D) 60 x 135.5 x 127 mm

Connections

0,5 - 10 mm² (WAGO series 831)

of which battery-buffered

2

with surge protection

2

Output current (details)

20 A

Input current

0.1 - 21.5 A

Weight

800 g

Width

60 mm

Height

135.5 mm

Depth

127 mm

Interfaces

RS232

Type

EPSITRON® 787-1675

Features

parameterisable

Bridging time, max load

0.5 s

Output voltage

24 V DC

Max. current

26 A

60

127 mm

135.5 mm

FALSE

FALSE

4

AC/DC

Spring clamp connection

TRUE

IP20

UKCA

not relevant

Documents & Downloads

Datasheet

Datasheet 414860 WAGO EPSITRON® 787-1675 787-1675 Industrial UPS

User & Safety Instructions

User & Safety Instructions 414860 WAGO EPSITRON® 787-1675 787-1675 Industrial UPS

Description

Charging and control unit for installation of an uninterruptible power supply (UPS).

Features

  • Current and voltage monitoring and configuration via LCD display and RS-232 interface
  • Active signal outputs for function monitoring
  • Remote input for switching off the buffered output
  • Input for temperature detection of the connected batteries.
