WAGO EPSITRON® 787-870 787-870 UPS switching module

EAN:
Part number:
Item no:
Power Supply Unit, Model 787-870, displays a screen and control elements. Suitable for industrial applications.
Datasheet (PDF)
Dispatches on Mon 7 Dec
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 385.00 / piece)
€ 385.00
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

UPS-charging and control unit

  • 28.3 V DC/ 20 A
  • Max. Charging current 0.6 A
  • Input voltage range 20.4 - 25.5 V DC
  • Connections: 0,08 - 2,5 mm² (WAGO series 231)

Technical specifications

Input voltage

20.4 - 25.5 V DC

Product type

UPS switching module

No. of outputs

2 x

Output

RS232

Input voltage (max.)

28.8 V DC

Min. input voltage

20.4 V DC

Output voltage (max.)

28.3 V DC

Output voltage (min.)

19.9 V DC

Dim

(W x H x D) 57 x 163 x 171 mm

Connections

0,08 - 2,5 mm² (WAGO series 231)

of which battery-buffered

2

with surge protection

2

Output current (details)

20 A

Input current

0.1 - 21.5 A

Weight

1200 g

Width

57 mm

Height

163 mm

Depth

171 mm

Interfaces

RS232

Type

EPSITRON® 787-870

Features

parameterisable

Bridging time, max load

10 s

Output voltage

24 V DC

Max. current

0.6 A

40

163 mm

163 mm

0.8 kg/m

DC

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 518965 WAGO EPSITRON® 787-870 787-870 UPS switching module

User & Safety Instructions

User & Safety Instructions 518965 WAGO EPSITRON® 787-870 787-870 UPS switching module

Description

Charging and control unit for installation of an uninterruptible power supply (UPS).

Features

  • Current and voltage monitoring and configuration via LCD display and RS-232 interface
  • Active signal outputs for function monitoring
  • Remote input for switching off the buffered output
  • Input for temperature detection of the connected batteries.
