1/3
WAGO Socket housing cable 831 Total number of pins 3 Contact spacing: 7.62 mm 831-3103 48 pc(s)
Product type
Socket housing cable
Connector type
Socket, straight
No. of rows
1
Series
831
CS
7.62 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
MCS MAXI terminal block
- Content: 48 pc(s)
- No. of rows: 1
- Total number of pins: 3
Technical specifications
- Product type
Socket housing cable
- Connector type
Socket, straight
- No. of rows
1
- Connector system
wire-to-board
- Series
831
- CS
7.62 mm
- Pins per row
3
- Total number of pins
3
- Width
41.90 mm
- Nominal current
41 A
- Nominal current - rounded value
41 A
- Content
48 pc(s)
- AWG max.
8
- AWG (min.)
20
- Stripping length (max.)
15.00 mm
- Dim
(L x W x H) 24.74 x 41.90 x 27.50 mm
- Connection
Spring-loaded terminal
- Case material
PA 66
- Manufacturer part #
831-3103
- Factory colour
Light grey
- Industrial packaging
Yes
- Contact material
Copper alloy
- Connector contact surface
Tin plated
- Nominal voltage
1000 V
- Height
27.50 mm
- Length
24.74 mm
- max. cross section
10 mm²
- Min. cross section
0.5 mm²
- Type
831-3103
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 657077 WAGO Socket housing cable 831 Total number of pins 3 Contact spacing: 7.62 mm 831-3103 48 pc(s)
User & Safety Instructions
User & Safety Instructions 657077 WAGO Socket housing cable 831 Total number of pins 3 Contact spacing: 7.62 mm 831-3103 48 pc(s)
