WAGO Socket housing PCB 769 Total number of pins 15 Contact spacing: 5 mm 769-645 25 pc(s)
Product type
Socket housing PCB
Connector type
Socket, vertical vertical
No. of rows
1
Series
769
CS
5 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
X-COM ® SYSTEM pin strip
- Content: 25 pc(s)
- No. of rows: 1
- Total number of pins: 15
Technical specifications
- Product type
Socket housing PCB
- Connector type
Socket, vertical vertical
- No. of rows
1
- Connector system
wire-to-board
- Series
769
- CS
5 mm
- Pins per row
15
- Total number of pins
15
- Width
78.60 mm
- Nominal current
53 A
- Nominal current - rounded value
53 A
- Content
25 pc(s)
- Dim
(L x W x H) 18.30 x 78.60 x 22.20 mm
- Connection
Print
- Case material
PA 66
- Manufacturer part #
769-645
- Factory colour
Grey
- Industrial packaging
Yes
- Contact material
Copper alloy
- Board contact surface
Tin plated
- Connector contact surface
Tin plated
- Nominal voltage
500 V
- Height
22.20 mm
- Length
18.30 mm
- Connector orientation
Perpendicular (to the PCB)
- Type
769-645
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 655596 WAGO Socket housing PCB 769 Total number of pins 15 Contact spacing: 5 mm 769-645 25 pc(s)
User & Safety Instructions
User & Safety Instructions 655596 WAGO Socket housing PCB 769 Total number of pins 15 Contact spacing: 5 mm 769-645 25 pc(s)
What kind of Pin Headers, Receptacles systems are you looking for?
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
Conrad Electronic
€ 45.99*
1 m = € 1.84
