Weidmüller 1473620000 Screw terminal 1.5 mm² Number of pins 11 Black 320 pc(s) Piece
Packaging type
Piece
Product type
Screw terminal
CS
3.5 mm
Pins per row
11
Number of pins
11
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
- Content 320 pc(s)
Our service for you
Technical specifications
- Packaging type
Piece
- Type
LSF-SMD 3.50/11/90 SN BK RL
- Product type
Screw terminal
- CS
3.5 mm
- No. of rows
1
- Pins per row
11
- Number of pins
11
- Series
LSF
- Min. stripping length
8 mm
- Stripping length (max.)
8 mm
- Nominal current
12 A
- Cross section (flexible) (min.)
0.2 mm²
- Nominal current - rounded value
12 A
- Cross section (inflexible) (min.)
0.2 mm²
- Cross section (flexible) (max.)
1.5 mm²
- Cross section (inflexible) (max.)
1.5 mm²
- AWG (min.)
28
- Connector orientation
Parallel (to the PCB)
- AWG max.
14
- Contact material
Copper alloy
- Factory colour
Black
- Actuation direction
Parallel (to the PCB)
- Weight
7.03 g
- Manufacturer part #
1473620000
- Content
320 pc(s)
- Nominal voltage
300 V
- Width
39.2 mm
- Height
9.65 mm
- Length
14.75 mm
- Type
LSF-SMD 3.50/11/90 SN BK RL
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1950347 Weidmüller 1473620000 Screw terminal 1.5 mm² Number of pins 11 Black 320 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 1950347 Weidmüller 1473620000 Screw terminal 1.5 mm² Number of pins 11 Black 320 pc(s) Piece
