Weidmüller 1562870000 HSS-HF 2.4-4.8 EL B30M Cable markers Fitting type: Cable tie Blue 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cable markers
Fitting type
Cable tie
Type
HSS-HF 2.4-4.8 EL B30M
Material
Polyolefin
Features
Halogen-free
Datasheet (PDF)
Technical specifications
- Depth: 0.9 mm
- Net weight: 293 g
- conductor cross-section, max.: 4 mm²
- conductor cross-section, min.: 0.75 mm²
- Type
HSS-HF 2.4-4.8 EL B30M
- Product type
Cable markers
- Fitting type
Cable tie
- Material
Polyolefin
- Features
Halogen-free
- Series
HSS-HF
- Min. temperature
-55 °C
- Max. temperature
+105 °C
- Suitable for outside Ø (min.)
2.4 mm
- Suitable for outside Ø (max.)
4.8 mm
- Factory colour
Blue
- Dim
(L x W) 30 m x 7.6 mm
- Halogen-free
Yes
- Content
1 pc(s)
- Dimensions
30000 mm
- Width
7.6 mm
- Length
30 m
- RoHS-compliant
Yes
- UKCA
yes
