Weidmüller 1760974001 PCB connector Total number of pins 3 No. of rows 1 265 pc(s)
Product type
PCB connector
Total no. of pins
3
CS
3.5 mm
Content
265 pc(s)
Total number of pins
3
EAN:
Part number:
Item no:
Highlights & Details
- Total number of pins 3
- No. of rows 1
- Content 265 pc(s)
Our service for you
Technical specifications
- Product type
PCB connector
- Total no. of pins
3
- Total number of pins
3
- No. of rows
1
- CS
3.5 mm
- Nominal current
10 A
- Nominal current - rounded value
10 A
- Pins per row
3
- Connection
THT
THR
Soldering
- Factory colour
Black
- Case material
PA
- Manufacturer part #
1760974001
- Content
265 pc(s)
- Contact material
CuSn
- Width
17.5 mm
- Height
12.6 mm
- Max. temperature
+100 °C
- Min. temperature
-50 °C
- Type
SL-SMT 3.50/03/180F 1.5SN BK RL
- Dim
(W x H) 17.5 mm x 12.6 mm
- Connector contact surface
Tin plated
- Dimensions
17.5 mm x 12.6 mm x 7.5 mm
- Nominal voltage
300 V
- Number of pins
3
- RoHS-compliant
Yes
- UKCA
not relevant
