Weidmüller 1815100000 Earth clamp Pull spring Green-yellow 50 pc(s)
Product type
Earth clamp
Connection
Pull spring
Cross section (flexible) (max.)
4 mm²
Cross section (inflexible) (max.)
4 mm²
Content
50 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Earth terminal
- ZTPE 2.5/3AN/1
Our service for you
Technical specifications
- Product type
Earth clamp
- Connection
Pull spring
- Cross section (flexible) (min.)
0.5 mm²
- Cross section (flexible) (max.)
4 mm²
- Cross section (inflexible) (min.)
0.5 mm²
- Cross section (inflexible) (max.)
4 mm²
- Factory colour
Green-yellow
- Manufacturer part #
1815100000
- Content
50 pc(s)
- Industrial packaging
Yes
- Type
ZTPE 2.5/3AN/1
- Dim
(L x W x H) 71.5 x 5.1 x 34.5 mm
- Width
5.1 mm
- Height
34.5 mm
- Length
71.5 mm
- RoHS-compliant
Yes
- Weight
12.34 g
- Type
ZTPE 2.5/3 ON/1
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 358933 Weidmüller 1815100000 Earth clamp Pull spring Green-yellow 50 pc(s)
User & Safety Instructions
User & Safety Instructions 358933 Weidmüller 1815100000 Earth clamp Pull spring Green-yellow 50 pc(s)
Description
Earthing terminal. Z-series terminal, rated cross-section: 2.5 mm², spring-cage connection, Wemid, green/yellow. A terminal strip for the function unit, a plug-in connectors for cable harness production. In Final Assembly are only two units zusammenzurasten-like connectors. And that's it! Whether in the application areas railway technology, mechanical engineering or shipbuilding - all serves the Z-series from weidmüller optimally. Because it is easy, fast and secure in the connection without any problem in the handling and practical in the system. Modular and flexible connection techniques are particularly in demand, where all function units pre-fabricated or replaced.
