Weidmüller 1845390000 Screw terminal 2.5 mm² Number of pins 4 Orange 50 pc(s)
Product type
Screw terminal
CS
5 mm
Pins per row
4
Number of pins
4
Connection
Print
Screw terminal
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Screw terminal block
Our service for you
Technical specifications
- Type
LM 5.00/04/135 3.5SN OR BX
- Product type
Screw terminal
- CS
5 mm
- No. of rows
1
- Pins per row
4
- Number of pins
4
- Series
LM
- Min. stripping length
6 mm
- Stripping length (max.)
6 mm
- Connection
Print
Screw terminal
- Nominal current
15 A
- Cross section (flexible) (min.)
0.2 mm²
- Nominal current - rounded value
15 A
- Cross section (inflexible) (min.)
0.2 mm²
- Cross section (flexible) (max.)
2.5 mm²
- Cross section (inflexible) (max.)
2.5 mm²
- AWG (min.)
24
- Connector orientation
At an angle (to the PCB)
- AWG max.
14
- Contact material
Cu-alloy, tin plated
- Factory colour
Orange
- Wire protection
Yes
- Actuation direction
At an angle (to the PCB)
- Weight
5.3 g
- Manufacturer part #
1845390000
- Industrial packaging
Yes
- Content
50 pc(s)
- Nominal voltage
300 V
- Width
20 mm
- Height
19 mm
- Length
13.9 mm
- Type
LM 5.00/04/135 3.5SN OR BX
- UKCA
not relevant
