Weidmüller 1861110000 Sensor/actuator built-in connector M12 Socket, built-in 0.50 m No. of pins (RJ): 8 1 pc(s)
Product type
Sensor/actuator built-in connector
Connector type
Socket, built-in
Connector standard
Sensor connector
Connection side A
Cable, open end
Connection side B
M12 socket, built-in
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Installation plug
- SAIE-M 12S -8-0. 5U-M16
Technical specifications
- Type
SAIE-M12S-8-0.5U-M16
- Product type
Sensor/actuator built-in connector
- Connector type
Socket, built-in
- Connector standard
Sensor connector
- Connection side A
Cable, open end
- Connection side B
M12 socket, built-in
- No. of pins
8
- Cable length
0.50 m
- Nominal voltage
250 V
- Nominal current
1 A
- Nominal current - rounded value
1 A
- Connection
Open end cable
- Thread type connection side
M12
- Coding
A
- Min. temperature
-25 °C
- Max. temperature
+85 °C
- Seal type
Screw-on
- Manufacturer part #
1861110000
- Content
1 pc(s)
- RoHS-compliant
Yes
Front mounting
Polyurethane (PUR)
30 V
0.5 m
8
Brass
Nickel-plated
-25-85 °C
Gold
IP67
2 A
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 204311 Weidmüller 1861110000 Sensor/actuator built-in connector M12 Socket, built-in 0.50 m No. of pins (RJ): 8 1 pc(s)
User & Safety Instructions
User & Safety Instructions 204311 Weidmüller 1861110000 Sensor/actuator built-in connector M12 Socket, built-in 0.50 m No. of pins (RJ): 8 1 pc(s)
Description
Built-in plug. M12, pin, straight, M16, poles: 3, 0.5 m.
