Weidmüller 1888310000 STR CC 15/17 Device markers Fitting type: Adhesive Writing area: 15 x 17 mm Transparent No. of mar
Product type
Device markers
Fitting type
Adhesive
Writing area length
15 mm
Writing area width
17 mm
Type
STR CC 15/17
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Device marker multi-card
Our service for you
Technical specifications
- Depth: 0.5 mm
- Net weight: 0.2 g
- Flammability class according to UL 94: HB
- Type
STR CC 15/17
- Product type
Device markers
- Fitting type
Adhesive
- Writing area length
15 mm
- Writing area width
17 mm
- Writing area
15 x 17 mm
- Material
PVC
- Suited for series
Devices and appliances
Universal usage
- Features
Printable
UL94 flammability rating
- Series
STR
- Min. temperature
-20 °C
- Max. temperature
+80 °C
- Factory colour
Transparent
- No. of markers
80
- Dim
(L x W x H) 15 x 17 x 15 mm
- Industrial packaging
Yes
- Content
80 pc(s)
- Width
17 mm
- Height
15 mm
- Length
15 mm
- RoHS-compliant
Yes
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 363930 Weidmüller 1888310000 STR CC 15/17 Device markers Fitting type: Adhesive Writing area: 15 x 17 mm Transparent No. of mar
User & Safety Instructions
User & Safety Instructions 363930 Weidmüller 1888310000 STR CC 15/17 Device markers Fitting type: Adhesive Writing area: 15 x 17 mm Transparent No. of mar
Description
With their razor-sharp printed writing area in different sizes, the multi-functional clip card engraved geratemarkierern at eye level as the ideal alternative for the labelling of electrical installations and switching systems, operate the entire spectrum of fixing methods. From the simple device labelling on the identification of pipes, valves, motors or lamps in accordance with DIN V VDE V 0108 (Part 100) to the type plate creation including colored company logo.
