Weidmüller 2651300000 PCB terminal 1.5 mm² Number of pins 18 Green 1 pc(s) Box
Packaging type
Box
Product type
PCB terminal
CS
5 mm
Number of pins
18
Connection
Soldering
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
PCB terminal, 400 V, 20 A, pitch in mm: 5.00, 2.5 mm², number of pins: 18, bracket connection, THT solder connection, 135°,box
- Content 1 pc(s)
Technical specifications
- Packaging type
Box
- Type
TSS 5.00/18/135 3.3SN GN BX
- Product type
PCB terminal
- CS
5 mm
- Number of pins
18
- Connection
Soldering
- Nominal current
20 A
- Cross section (flexible) (min.)
0.2 mm²
- Nominal current - rounded value
20 A
- Cross section (inflexible) (min.)
0.2 mm²
- Cross section (flexible) (max.)
1.5 mm²
- Cross section (inflexible) (max.)
2.5 mm²
- Connector orientation
At an angle (to the PCB)
- Enclosure material
Polyamide
- Factory colour
Green
- Manufacturer part #
2651300000
- Content
1 pc(s)
- Nominal voltage
400 V
- Type
TSS 5.00/18/135 3.3SN GN BX
Green
400 V
-40-105 °C
Solder
4 kV
6021
II
2
Screw connection
Soldering connection
3.3 mm
5 mm
Other
0.2-2.5 mm²
0.2-1.5 mm²
0.2-1.5 mm²
Polyamide (PA)
45°/135° (downwards inclined)
Other
18
V0
Documents & Downloads
Datasheet
Datasheet 3767794 Weidmüller 2651300000 PCB terminal 1.5 mm² Number of pins 18 Green 1 pc(s) Box
User & Safety Instructions
User & Safety Instructions 3767794 Weidmüller 2651300000 PCB terminal 1.5 mm² Number of pins 18 Green 1 pc(s) Box
Description
PCB terminal (PCB terminal, circuit board terminal) for secure, simple data transfer directly to the PCB.
