Weidmüller 2764920000 Bus cable 2 x 0.34 mm² Violet 1 pc(s)
EAN:
Part number:
Item no:
Product type
Bus cable
No. of leads
2 x
Cross section (each core)
0.34 mm²
Cross section
2 x 0.34 mm²
Cable features
Oil-resistant
Technical specifications
- Contact surface: Gold-plated
- Product type
Bus cable
- No. of leads
2 x
- Cross section (each core)
0.34 mm²
- Cross section
2 x 0.34 mm²
- Cable features
Oil-resistant
- Outside Ø
7.8 mm
- Type
500 m
- Factory colour
Violet
- Content
1 pc(s)
- Bend radius (no. of ODs for fixed installation)
18
- Bend radius (no. of ODs for flexible installation)
9
- Halogen-free
No
- Shielded
Yes
- Manufacturer part #
2764920000
- Insulation material
PVC
- Min. temperature range (fixed installation)
-20 °C
- Max. temperature range (fixed installation)
+70 °C
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (flexible installation)
+60 °C
- RoHS-compliant
Yes
- Type
SAIH-PB-2X0.34-PVC-500
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3361445 Weidmüller 2764920000 Bus cable 2 x 0.34 mm² Violet 1 pc(s)
