Weidmüller 9455650000 Sensor/actuator built-in connector M12 Plug, mount 150 mm No. of pins (RJ): 4 1 pc(s) Piece
Product type
Sensor/actuator built-in connector
Connector type
Plug, mount
Connector standard
Sensor connector
Connection side A
Cable, open end
Connection side B
M12 plug, built-in
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Positioning Connector
- POS-4P M12 PG 13.5 150 mm
Our service for you
Technical specifications
- Packaging type
Piece
- Type
POS-4P M12 PG13,5 150MM
- Product type
Sensor/actuator built-in connector
- Connector type
Plug, mount
- Connector standard
Sensor connector
- Connection side A
Cable, open end
- Connection side B
M12 plug, built-in
- No. of pins
4
- Cable length
150 mm
- Nominal voltage
250 V
- Nominal current
4 A
- Nominal current - rounded value
4 A
- Connector cross-section (max.)
1.5 mm²
- Connection
Open end cable
- Thread type connection side
M12
IP67
- Features
Industrial-grade
- Min. temperature
-40 °C
- Max. temperature
+85 °C
- Seal type
Screw-on
- Manufacturer part #
9455650000
- Content
1 pc(s)
- RoHS-compliant
Yes
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 259678 Weidmüller 9455650000 Sensor/actuator built-in connector M12 Plug, mount 150 mm No. of pins (RJ): 4 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 259678 Weidmüller 9455650000 Sensor/actuator built-in connector M12 Plug, mount 150 mm No. of pins (RJ): 4 1 pc(s) Piece
Description
Positioning connectors. M12, poles: 4. The FBCon fieldbus distributor are in industry and in the EEx(ia) version available. They are used for the coupling of 1 - 8 field devices or sensors. The connection is made via spur lines. The connection of the stub line is optionally available as M12 plug connection or directly with EMC cable gland. The communication, and the device is powered via a common 2-wire line. The distributors offer depending on the version the following properties: Spring-cage connection. With surge protection for the main line. With current limiter (limiter) for each stub. Emc cable gland. M12 plug connector Outer an earth connection. Uninterrupted bus operation. Industrial design. Bus Termination integrated (non-Ex). EX-Version ATEX. Pressure compensation element, type of protection IP65, IP66, IP67. Stainless steel design, PROFIBUS-PA compatible.
