Weidmüller 9456170060 Sensor/actuator connector (pre-fab) M12 Plug, straight, Plug, right angle 0.60 m No. of pins (RJ):
Product type
Sensor/actuator connector (pre-fab)
Connector type
Plug, straight
Plug, right angle
Connector standard
Sensor connector
Connection side A
M12 plug, straight
Connection side B
M12 plug, straight
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Solenoid Connectors
- SAIL-VSCD-M 12G-0.6 U
Technical specifications
- Type
SAIL-VSCD-M12G-0.6U
- Product type
Sensor/actuator connector (pre-fab)
- Connector type
Plug, straight
Plug, right angle
- Connector standard
Sensor connector
- Connection side A
M12 plug, straight
- Connection side B
M12 plug, straight
- No. of pins
3
- Cable length
0.60 m
- Jacket material
PUR
- Nominal voltage
24 V
- Nominal current
4 A
- Nominal current - rounded value
4 A
- Cross-section (sensor/actuator wiring)
0.5 mm²
- Thread type connection side
M12
- Cable colour
Black
- Min. temperature
-25 °C
- Max. temperature
+80 °C
- Seal type
Screw-on
- Manufacturer part #
9456170060
- Content
1 pc(s)
- RoHS-compliant
Yes
- Cable diameter (details)
4.60
TRUE
24 V
0.6 m
FALSE
3
-25-80 °C
-50-80 °C
Tin
IP67
Other
Other
TRUE
4 A
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 259734 Weidmüller 9456170060 Sensor/actuator connector (pre-fab) M12 Plug, straight, Plug, right angle 0.60 m No. of pins (RJ):
User & Safety Instructions
User & Safety Instructions 259734 Weidmüller 9456170060 Sensor/actuator connector (pre-fab) M12 Plug, straight, Plug, right angle 0.60 m No. of pins (RJ):
Description
Valve plug. Straight plug, CD. Weidmüller offers valve plug as a connection cable with M12 plugs and with free cable end. The operating state of the valve plug is used by a display element (LED) lights. The valve plug, all a protective circuit. The Weidmüller products include valve plug of the types A, B, C according to DIN and industry standard. The protection class IP67 is when mated. The outlet direction is also crucial. At Weidmüller are 0 degrees versions available, that is, the cable outlet direction, the PE contact.
