Weidmüller CLI C 1-6 GE/SW 70 CD Ring Imprint 70 Outside diameter range 2.5 up to 5 mm 1868811591
Product type
Ring
Imprint
70
Suitable for outside Ø (min.)
2.5 mm
Suitable for outside Ø (max.)
5 mm
Dim
(L x W x H) 5 x 4.2 x 6 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Lead marker cable line ® CLI C
- No. of markers: 250
- Imprint: 70
Our service for you
Technical specifications
- Net weight: 0.156 g
- Printing color: Black
- Printing method: Hot embossed
- Material color according to resistance code: 4
- Orientation of the imprint: Horizontal
- Insulation diameter, max.: 5 mm
- conductor cross-section, max.: 4 mm²
- conductor cross-section, min.: 1.5 mm²
- Product type
Ring
- Dim
(L x W x H) 5 x 4.2 x 6 mm
- Imprint
70
- Type
Numbers
- Series
CableLine® CLI C
- Suitable for
CableLine® CLI C
- Factory colour
Yellow
- Material
PVC
- Suitable for outside Ø (min.)
2.5 mm
- Suitable for outside Ø (max.)
5 mm
- Min. temperature
-30 °C
- Max. temperature
+80 °C
- Features
UL94 flammability rating
halogen-free
- No. of markers
250
- Outside diameter range
2.5 up to 5 mm
- Colour-coded
Yes
- Halogen-free
Yes
- Manufacturer part #
1868811591
- Industrial packaging
Yes
- Content
250 pc(s)
- Width
4.2 mm
- Height
6 mm
- Length
5 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 362137 Weidmüller CLI C 1-6 GE/SW 70 CD Ring Imprint 70 Outside diameter range 2.5 up to 5 mm 1868811591
Description
Lead marker. 6 x 4.2 mm, PVC, soft, without cadmium, color: yellow. CLI C-lead marker are not connected conductor mounted. Conductor cross-sections of 0,5mm² up to a maximum of 70 mm² can be with four different sizes. The markers are printed. Closed marker, safe and adjusted to non-connected lines. Wide area of use by means of a special bellows profile with spring effect. Fast, easy mounting with a flick of the wrist. The corresponding accessories facilitates the marker work. Permanent marking of high quality. Best contrasts for optimum readability.
This text is machine translated.
This text is machine translated.
Scope of delivery
- roller
