Weidmüller KTB QL 352615 S4E1 Fitting bracket 260 x 350 x 150 Stainless steel Silver 1 pc(s) Piece
Packaging type
Piece
Product type
Fitting bracket
Material
Stainless steel
IP rating
IP66
Width
260 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Cases & Enclosures
- KTB QL 352615 S4 E1
- This text is machine translated.
Technical specifications
- Mounting dimensions Width: 286 mm
- Mounting dimensions Height: 250 mm
- Operating temperature, max.: +135 °C
- Operating temperature, min.: -60 °C
- Lid fixing: Quarter-turn lock with slot insert
- Sealing material: Silicone
- Mounting mounting: 4.6 or 9 stud bolts M6 Internal thread
- Mounting plate Mounting note: Mounting rail /
- grounding Internal housing: Welded M6 Stainless steel grounding bolts in the lower part and cover
- Flange plates: Bottom
- housing mounting: Housing mounting: 4 welded mounting feet with 11 mm hole size (2 slot and 2 circular mounting feet)
- Material thickness: 1.5 mm
- Material thickness Cover: 1.5 mm
- Material thickness Flange: 3 mm
- Standards: DIN EN 62208 - Empty housing Standard, DIN EN 61373 Class 1B**, DIN EN 15085-2, EN 60079-0, EN 60079-7, EN 60079-31, IEC 60079-0, IEC 60079-7, IEC 60079-31
- Surface: Electropolished
- opening angle Cover: 130 °
- Key width 1: 10 mm
- Access opening Width: 201 mm
- Access opening Height: 297 mm
- Packaging type
Piece
- Product type
Fitting bracket
- Features
with bolt
- Material
Stainless steel
IP66
- Factory colour
Silver
- Width
260 mm
- Height
350 mm
- Dimensions
260 x 350 x 150 mm
- Weight
7 g
- Content
1 pc(s)
- Type
KTB QL 352615 S4E1
- Dim
(W x H x D) 260 x 350 x 150 mm
- RoHS-compliant
Yes
- Manufacturer part #
1200120000
- Depth
150 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 201477 Weidmüller KTB QL 352615 S4E1 Fitting bracket 260 x 350 x 150 Stainless steel Silver 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 201477 Weidmüller KTB QL 352615 S4E1 Fitting bracket 260 x 350 x 150 Stainless steel Silver 1 pc(s) Piece
Description
With Earthing bolts in the housing cover and base. Mounting feet welded.
This text is machine translated.
This text is machine translated.
Scope of delivery
- With silicone seal.
