Weidmüller Socket housing cable BL/SL Total number of pins 3 Contact spacing: 7.62 mm 1980490000 100 pc(s)
Product type
Socket housing cable
Connector type
Socket, straight
No. of rows
1
Series
BL/SL
CS
7.62 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
PCB connector
- Content: 100 pc(s)
- No. of rows: 1
- Total number of pins: 3
Our service for you
Technical specifications
- Product type
Socket housing cable
- Connector type
Socket, straight
- No. of rows
1
- Connector system
wire-to-board
- Series
BL/SL
- Features
+ latch
- CS
7.62 mm
- Pins per row
3
- Total number of pins
3
- Width
23.30 mm
- Nominal current
20 A
- Nominal current - rounded value
20 A
- Content
100 pc(s)
- AWG max.
12
- AWG (min.)
20
- Stripping length (max.)
7.00 mm
- Dim
(L x W x H) 18.30 x 23.30 x 22.86 mm
- Connection
Screw terminal
Plug
- Case material
PBT
- Manufacturer part #
1980490000
- Industrial packaging
Yes
- Contact material
Cu-alloy, tin plated
- Connector contact surface
Tin plated
- Nominal voltage
600 V
- Height
22.86 mm
- Length
18.30 mm
- max. cross section
4.00 mm²
- Min. cross section
0.20 mm²
- RoHS-compliant
Yes
- Connector orientation
Perpendicular (to the PCB)
- Type
BLZ 7.62HP/03/180 SN OR BX
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 390566 Weidmüller Socket housing cable BL/SL Total number of pins 3 Contact spacing: 7.62 mm 1980490000 100 pc(s)
User & Safety Instructions
User & Safety Instructions 390566 Weidmüller Socket housing cable BL/SL Total number of pins 3 Contact spacing: 7.62 mm 1980490000 100 pc(s)
Description
PCB connector. Jack plug, 7.62 mm, number of poles: 3, 180°, receptacle, max.: 4 mm², Box. Power on board - 100% security, 100% Integration, 100% cost-effectiveness: The compact and efficient solution for UL-600 V applications in the lower performance range. Socket strip in HP (High Performance) Version for applications up to 12 kVA: 29A at 400 V (IEC), 18.5 A at 600 V (UL), 0.08 - 4 mm²/AWG 28 - 12. The vicarious agent of the device approval: meets the requirements for 600 V, according to UL 508/UL 840. Meets the high requirements when mated to the protective cover in accordance with IEC 68100-5-1. The Schlankheitskur for multi-stage device series: Reduce size and cost of high-volume, low-end performance range - without compromising on the approval!.
