Weidmüller Socket housing cable BL Total number of pins 2 Contact spacing: 7.62 mm 1173490000 70 pc(s)
Product type
Socket housing cable
Connector type
Socket, straight
No. of rows
1
Series
BL
CS
7.62 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
PCB connector
- Content: 70 pc(s)
- No. of rows: 1
- Total number of pins: 2
Our service for you
Technical specifications
- Product type
Socket housing cable
- Connector type
Socket, straight
- No. of rows
1
- Connector system
wire-to-board
- Series
BL
- Features
+ locking mechanism
- CS
7.62 mm
- Pins per row
2
- Total number of pins
2
- Width
23.40 mm
- Nominal current
20 A
- Nominal current - rounded value
20 A
- Content
70 pc(s)
- AWG max.
12
- AWG (min.)
20
- Stripping length (max.)
7.00 mm
- Dim
(L x W x H) 21.20 x 23.40 x 22.14 mm
- Connection
Screw terminal
Plug
- Case material
PBT
- Manufacturer part #
1173490000
- Industrial packaging
Yes
- Contact material
Cu-alloy, tin plated
- Connector contact surface
Tin plated
- Nominal voltage
600 V
- Height
22.14 mm
- Length
21.20 mm
- max. cross section
4.00 mm²
- Min. cross section
0.08 mm²
- RoHS-compliant
Yes
- Connector orientation
Perpendicular (to the PCB)
- Type
BLZ 7.62IT/02/180MF2 SN BK BX
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 314087 Weidmüller Socket housing cable BL Total number of pins 2 Contact spacing: 7.62 mm 1173490000 70 pc(s)
User & Safety Instructions
User & Safety Instructions 314087 Weidmüller Socket housing cable BL Total number of pins 2 Contact spacing: 7.62 mm 1173490000 70 pc(s)
Description
PCB connector. Jack plug, 7.62 mm, number of poles: 2, 180°, receptacle, max.: 4 mm², Box. 180° socket plug in grid 7.62 for IT networks. Complies with the requirements of UL 1059 600 V Class C. In connection with the terminal strip SL 7.62 IT.... with leading PE contact. Meets the extended challenges to 5.5 mm finger-safety for IT networks in accordance with IEC 61800-5-1 for 400 V against earth. The self-locking, optionally also additional screw center flange reduces the space required compared to conventional solutions with a raster width. On request, even without a center flange locking available. 0.08 - 4.0 mm² (IEC) / 28 - 12 AWG (UL), 400 V (IEC) / 600 V (UL), 29 A (IEC) / 20 A (UL).
This text is machine translated.
This text is machine translated.
