Wiska 10107118 BCIV-S-36-BG Conduit Grey 36 mm 25 m
EAN:
Part number:
Item no:
Product type
Conduit
Content
25 m
Material
Polyamide 12
Conduit features
halogen-free
UV-resistant
oil-resistant
Inside diameter
36 mm
Datasheet (PDF)
Number
Total (1 m = € 13.96)
€ 465.00
-25 %
€ 349.00
incl. VAT
14-day return policy included
Highlights & Details
CORRUGATED TUBE PA12 UL94-V2
Our service for you
Technical specifications
- Product type
Conduit
- Content
25 m
- Factory colour
Grey
- Material
Polyamide 12
- Conduit features
halogen-free
UV-resistant
oil-resistant
- Inside diameter
36 mm
- Outside Ø
42.3 mm
- Max. temperature
+110 °C
- Min. temperature
-40 °C
- Length
25 m
- Bend radius
81 mm
- Fire protection properties
V2
- Manufacturer part #
10107118
- RoHS-compliant
Yes
- Type
BCIV-S-36-BG
Documents & Downloads
Datasheet
Datasheet 2479568 Wiska 10107118 BCIV-S-36-BG Conduit Grey 36 mm 25 m
User & Safety Instructions
User & Safety Instructions 2479568 Wiska 10107118 BCIV-S-36-BG Conduit Grey 36 mm 25 m
Description
Plastic protective hose to protect cables from mechanical stress, sand and moisture.
