Axial screw contact 09110006156 HARTING Content: 1 pc(s) Axial screw contact
Packaging type
Piece
Product type
Axial screw contact
Type
09110006156
Manufacturer part #
09110006156
Connection
Axial screw terminal
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 93.99 / piece)
€ 93.99
incl. VAT
14-day return policy included
Technical specifications
- Net weight: 133.72 g
- Wire cross-section: 35 mm² - 70 mm²
- Gender: Pin
- Plug-in cycles: ≥ 500
- Contact type: Axial screw contact
- Tightening torque: 8 Nm - 35 mm², 10 Nm - 50 mm², 12 Nm - 70 mm²
- Contact surface: Silver-plated
- Forward resistance: ≤ 0.2 mΩ
- Operating current: ≤ 350 A
- Wire stripping length: 19 mm - 20 mm
- Packaging type
Piece
- Type
09110006156
- Product type
Axial screw contact
- Manufacturer part #
09110006156
- Connection
Axial screw terminal
- Total no. of pins
+ PE
- Content
1 pc(s)
- Material
Copper alloy
- Max. temperature
+125 °C
- Leading contact (PE)
Yes
- UKCA
yes
