Barthelme 58500211 LED indicator light Red 24 V DC/AC
Product type
LED indicator light
Operating voltage
24 V DC/AC
Recess diameter
16 mm
IP rating
IP40
Connection
Solder lug
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 7.49 / piece)
€ 7.49
incl. VAT
14-day return policy included
Highlights & Details
LED signal lamp round 18 x 39 mm IP40
Our service for you
Technical specifications
- Product type
LED indicator light
- Type
5850 0211
- Factory colour
Red
- Operating voltage
24 V DC/AC
- Recess diameter
16 mm
- Mounting depth
30 mm
- Head Ø
18 mm
- Head height
14.8 mm
- Front panel thickness
1 - 6 mm
- Case colour
Black
- Mounting type
Screw and union
IP40
- Connection
Solder lug
- Dim
(Ø x L) 18 mm x 39 mm
- Length
39 mm
- (Ø)
18 mm
- Min. temperature
-25 °C
- Max. temperature
+55 °C
- RoHS-compliant
Yes
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 1517237 Barthelme 58500211 LED indicator light Red 24 V DC/AC
User & Safety Instructions
User & Safety Instructions 1517237 Barthelme 58500211 LED indicator light Red 24 V DC/AC
Description
The LED signal lamps with a built-diameter of 16 mm are suitable for visual display of operating states on machines, equipment, etc. They are fixed with screw thread and lock nut (wall thickness 1 - 6 mm).
This text is machine translated.
This text is machine translated.
