Benning CM 12 Clamp meter Calibrated to (ISO standards) Digital ISO calibration CAT IV 600 V Display (counts): 9999
EAN:
Part number:
Item no:
Highlights & Details
CM 12
- CAT IV 600 V
Technical specifications
- Voltage reading range DC (min.)
10 mV
- Product type
Clamp meter
- Voltage DC reading range (max.)
1000 V
- V AC reading range (min.)
10 mV
- V AC reading range (max.)
1000 V
- Amperage reading range DC (min.)
10 mA
- A DC reading range (max.)
600 A
- A AC reading range (min.)
10 mA
- Amperage reading range AC (max.)
600 A
- Reading range - resistance
0.1 Ohm - 100 kOhm
- Reading range - capacity
1 nF - 4 mF
- Frequency reading range
0.01 Hz - 10 kHz
- Basic accuracy
1 %
- Measurement type (details)
True RMS
- Interfaces
Bluetooth®
ISO standards
- Reading category
CAT IV 600 V
- Current reading
AC/DC
- Type
CM 12
- Display
Digital
- Display (counts)
9999
- Features
ISO calibration
- Interfaces
Bluetooth®
- Opening range of current clamps
33 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2435349 Benning CM 12 Clamp meter Calibrated to (ISO standards) Digital ISO calibration CAT IV 600 V Display (counts): 9999
Description
Digital clamp-on ammeter for highest demands on accuracy.
This text is machine translated.
This text is machine translated.
Features
- Active power (AC/DC) and power factor measurement (cos ϕ)
- Measurement of inrush currents (motors, etc.)
- Low pass filter (HFR), THD harmonic measurement
- Volt sensor for non-contact cable break test (red LED)
- Two pin rotating testing
- Data logger (9999 measured values) and memory function
- BluetoothTM Low Energy 4.0 interface
- Free IOS and Android APP for smartphone/tablet
- LC-display with bar graph display and background lighting
- MEMORY FUNCTION: A-SAVE, HOLD, MIN, MAX, PEAK, AVG, INRUSH
Scope of delivery
- Supplied with bag, batteries and test leads
