binder 99-4830-00-08 Series 440 Miniature Circular Connector Nominal current (details): 5 A Pins: 8 DIN
EAN:
Part number:
Item no:
Product type
Bullet connector
Connector type
Plug, straight
Total no. of pins
8
Connection
Soldering
Content
1 pc(s)
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 26.04
3
4% = € 1.13
€ 24.91
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 26.04 / piece)
€ 29.40
-11 %
€ 26.04
plus VAT.
Only 4 Piece(s) available
binder 99-4830-00-08 Series 440 Miniature Circular Connector Nominal current (details): 5 A Pins: 8 DIN
Highlights & Details
- IP67
Technical specifications
- Type
99-4830-00-08
- Product type
Bullet connector
- Connector type
Plug, straight
- Total no. of pins
8
- Connection
Soldering
- Content
1 pc(s)
- Nominal current
5 A
- Nominal current - rounded value
5 A
- Seal
Push-pull
- Nominal voltage
60 V
- Contact material
Gold plated
- Cable Ø (max.)
8 mm
- Cable Ø up to
4 mm
20
- Connection angle
180°
- Manufacturer part #
99-4830-00-08
- Cable Ø range
4 - 8 mm
- Number of pins
8
- max. cross section
0.75 mm²
- Cross-section range
0.75 mm² (max)
IP67
- Series
440
- Type
Cable connector
- Nominal voltage (details)
60 V
- Nominal current (details)
5 A
- Contamination level
1
- Cross section
0.75 mm²
- Pins
8 DIN
- Connection
Solder
- Cable diameter
4 - 8 mm
- Temperature range
-25 - +85 °C
Documents & Downloads
Datasheet
Datasheet 735838 binder 99-4830-00-08 Series 440 Miniature Circular Connector Nominal current (details): 5 A Pins: 8 DIN
User & Safety Instructions
User & Safety Instructions 735838 binder 99-4830-00-08 Series 440 Miniature Circular Connector Nominal current (details): 5 A Pins: 8 DIN
Description
· Connector with push-pull locking
· Shieldable cable connector with excellent EMC properties
· Pressure screw with vibration damper.
· Shieldable cable connector with excellent EMC properties
· Pressure screw with vibration damper.
