Name: BLOCK PC-0724-480-0 RCCB 24 V DC 6 A No. of outputs:8 x Content 1 pc(s)
Brand: BLOCK
SKU: 2757962
Availability: InStock

'Three silver electronic devices with black control panels arranged diagonally side by side.'

Image similar

Fast track dispatch on Thu 15 Oct

1 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 149.99 / piece)

€ 149.99

incl. VAT

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Electronic. Protection switch

Adjustable nominal current per channel
Reliable switching on of high capacitive loads
Status query and remote switching of outputs via 2 lines
Total error message
Push-In connection technology
LED signaling and remote query per channel
Robust mounting rail made of die-cast zinc
Slim design

Technical specifications

Output current (max.) 8 x 1/2/3/4/5/6 A (adjustable)

Nominal input voltage: 24 V/DC

Product type: RCCB

Min. input voltage: 18 V DC

Output voltage: 24 V DC

Inputs: 1

Input voltage: 18 - 30 V DC

Input voltage (max.): 30 V DC

Max. output current: 6 A

Output current (max.) - rounded: 6 A

Output type (power supply units): Adjustable

Output voltage (nominal): 24 V DC

No. of outputs: 8 x

Connection: Push-in connector

Dim: (L x W x H) 124 x 42 x 127 mm

Weight: 400 g

Output voltage (max.): 24 V DC

Output voltage (min.): 24 V DC

Manufacturer part #: PC-0724-480-0

Content: 1 pc(s)

PSU features: Surge protection

Width: 42 mm

Height: 127 mm

Length: 124 mm

: IP20
Protection class III

Max. temperature: +70 °C

Min. temperature: -25 °C

Type: PC-0724-480-0

Efficiency: 99 %

Variants(All information include VAT, plus shipping costs)

Input voltage (max.)

Output voltage (nominal)

Output voltage

Output type (power supply units)

Nominal input voltage

No. of outputs

Output current (max.) - rounded

Product type

Min. input voltage

BLOCK PC-0724-480-0 RCCB 24 V DC 6 A No. of outputs:8 x Content 1 pc(s)

Item no:2757962

Fast track dispatch on Thu 15 Oct

1 Piece(s)Conrad Electronic

This article

30 V DC

24 V DC

Adjustable

24 V/DC

8 x

6 A

RCCB

18 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 149.99^*

BLOCK PC-0724-800-0 RCCB 24 V DC 10 A No. of outputs:8 x Content 1 pc(s)

Item no:2757965

Fast track dispatch on Thu 15 Oct

4 Piece(s)Conrad Electronic

30 V DC

24 V DC

Adjustable

24 V/DC

8 x

10 A

RCCB

18 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 159.99^*

BLOCK PC-0748-800-0 RCCB 48 V DC 10 A No. of outputs:8 x Content 1 pc(s)

Item no:2757963

Fast track dispatch on Thu 15 Oct

1 Piece(s)Conrad Electronic

58 V DC

48 V DC

Adjustable

48 V/DC

8 x

10 A

RCCB

32 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 214.99^*

BLOCK PC-0124-050-4 Rail mounted PSU (DIN) 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

Item no:2206896

Unavailable

Conrad Electronic

264 V AC

24 V DC

Adjustable

100 - 240 V/AC

1 x

5 A

Rail mounted PSU (DIN)

85 V AC

Piece(s)

Minimum order quantity: 1

Multiple: 1

BLOCK PC-0124-200-4 Rail mounted PSU (DIN) 24 V DC 20 A 480 W No. of outputs:1 x Content 1 pc(s)

Item no:2206897

Unavailable

Conrad Electronic

264 V AC

24 V DC

Adjustable

100 - 240 V/AC

1 x

20 A

Rail mounted PSU (DIN)

85 V AC

Piece(s)

Minimum order quantity: 1

Multiple: 1

BLOCK PC-0224-050-2 Rail mounted PSU (DIN) 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

Item no:2206990

Unavailable

Conrad Electronic

550 V AC

24 V DC

Adjustable

200 - 500 V/AC

1 x

5 A

Rail mounted PSU (DIN)

180 V AC

Piece(s)

Minimum order quantity: 1

Multiple: 1

BLOCK PC-0224-100-0 Rail mounted PSU (DIN) 24 V DC 10 A 240 W No. of outputs:1 x Content 1 pc(s)

Item no:2206898

Unavailable

Conrad Electronic

550 V AC

24 V DC

Adjustable

200 - 500 V/AC

1 x

10 A

Rail mounted PSU (DIN)

180 V AC

Piece(s)

Minimum order quantity: 1

Multiple: 1

BLOCK PC-0224-100-2 Rail mounted PSU (DIN) 24 V DC 10 A 240 W No. of outputs:1 x Content 1 pc(s)

Item no:2206922

Unavailable

Conrad Electronic

550 V AC

24 V DC

Adjustable

200 - 500 V/AC

1 x

10 A

Rail mounted PSU (DIN)

180 V AC

Piece(s)

Minimum order quantity: 1

Multiple: 1

BLOCK PC-0324-400-2 Rail mounted PSU (DIN) 24 V DC 40 A 960 W No. of outputs:1 x Content 1 pc(s)

Item no:2206991

Unavailable

Conrad Electronic

575 V AC

24 V DC

Adjustable

400 - 500 V/AC

1 x

40 A

Rail mounted PSU (DIN)

320 V AC

Piece(s)

Minimum order quantity: 1

Multiple: 1

BLOCK PC-0348-200-0 Rail mounted PSU (DIN) 48 V DC 20 A 960 W No. of outputs:1 x Content 1 pc(s)

Item no:2206836

Unavailable

Conrad Electronic

575 V AC

48 V DC

Adjustable

400 - 500 V/AC

1 x

20 A

Rail mounted PSU (DIN)

320 V AC

Piece(s)

Minimum order quantity: 1

Multiple: 1

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2757962 BLOCK PC-0724-480-0 RCCB 24 V DC 6 A No. of outputs:8 x Content 1 pc(s)

Description

The electronic circuit breaker splits the load current onto several 24 V feeders on and monitors them reliable for overload and short circuit. Short term current peaks, for example through a high inrush current, the electronics to, feeders with longer overload switches you dead. The trigger current of each output can be set individually with a current selector switch accessible from the front. The outputs are switched on time-displaced and load-dependent, in order to reduce peak inrush currents.

This text is machine translated.
