BLOCK VB 0,35/1/18 PCB mount transformer 1 x 230 V 1 x 18 V AC 0.35 VA 19 mA
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 5.03
5
6% = € 0.32
€ 4.71
10
9% = € 0.46
€ 4.57
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 5.03 / piece)
€
Only 8 Piece(s) available
Highlights & Details
BLOCK VB 0,35/1/18 PCB mount transformer 1 x 230 V 1 x 18 V AC 0.35 VA 19 mA
- Minimum size in case of high power
- Short-circuit resistant
Technical specifications
- Output voltage
18 V AC
- Output voltage (number x voltage)
1 x 18 V AC
- Output current
19 mA
- No. of inputs
1 x
- No. of outputs
1 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
0.35 VA
- Height
15 mm
- Type
VB 0,35/1/18
- Content
1 pc(s)
- Dim
- Test mark
C-UL-US, ENEC 10 (VDE)
- Connection
Soldering
0.35 VA
- Output voltage
18 V
- Insulation class
VDE=B, UL=105
- Frequency
50 - 60 Hz
- Efficiency
30 %
- RoHS-compliant
Yes
- Max. ambient temperature
+70 °C
- Test voltage
5000 V
- Weight
0.02 kg
- Product type
PCB mount transformer
Documents & Downloads
Datasheet
Datasheet 710575 BLOCK VB 0,35/1/18 PCB mount transformer 1 x 230 V 1 x 18 V AC 0.35 VA 19 mA
User & Safety Instructions
User & Safety Instructions 710575 BLOCK VB 0,35/1/18 PCB mount transformer 1 x 230 V 1 x 18 V AC 0.35 VA 19 mA
Conformity certificate
Conformity certificate 710575 BLOCK VB 0,35/1/18 PCB mount transformer 1 x 230 V 1 x 18 V AC 0.35 VA 19 mA
Description
VB voltage
Primary connection assignment: pin 1 to 2
Pin assignment Secondary: Pen 4-3
Primary connection assignment: pin 1 to 2
Pin assignment Secondary: Pen 4-3
Hints
Dimensional drawing see technical data sheet.
