BLOCK VB 2,8/1/6 PCB mount transformer 1 x 230 V 1 x 6 V AC 2.80 VA 466 mA
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 15.99 / piece)
€ 15.99
incl. VAT
14-day return policy included
Highlights & Details
BLOCK VB 2,8/1/6 PCB mount transformer 1 x 230 V 1 x 6 V AC 2.80 VA 466 mA
- Minimum size in case of high power
- Short-circuit resistant
Our service for you
Technical specifications
- Product type
PCB mount transformer
- Output voltage
6 V AC
- Output voltage (number x voltage)
1 x 6 V AC
- Output current
466 mA
- No. of inputs
1 x
- No. of outputs
1 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
2.80 VA
- Height
34 mm
- Type
VB 2,8/1/6
- Connection
Soldering
- Frequency
50 - 60 Hz
- Weight
0.14 kg
- Content
1 pc(s)
- Insulation class
VDE=B, UL=105
- Test voltage
5000 V
- Test mark
C-UL-US, ENEC 10 (VDE)
- RoHS-compliant
Yes
- Max. ambient temperature
+70 °C
- Efficiency
57 %
2.8 VA
- Output voltage
6 V/
Documents & Downloads
Datasheet
Datasheet 710432 BLOCK VB 2,8/1/6 PCB mount transformer 1 x 230 V 1 x 6 V AC 2.80 VA 466 mA
User & Safety Instructions
User & Safety Instructions 710432 BLOCK VB 2,8/1/6 PCB mount transformer 1 x 230 V 1 x 6 V AC 2.80 VA 466 mA
Conformity certificate
Conformity certificate 710432 BLOCK VB 2,8/1/6 PCB mount transformer 1 x 230 V 1 x 6 V AC 2.80 VA 466 mA
Description
VB voltage
Primary connection assignment: pin 1 to 2
Pin assignment Secondary: Pen 4-3
Primary connection assignment: pin 1 to 2
Pin assignment Secondary: Pen 4-3
Hints
Dimensional drawing see technical data sheet.
