Bourns 4605X-101-222LF Resistor ladder 2.2 kΩ THT SIP 5 0.2 W 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
7
-
€ 0.366
21
9% = € 0.03
€ 0.333
35
13% = € 0.05
€ 0.319
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 7
Total (€ 0.366 / piece)
€ 2.56
plus VAT.
Technical specifications
- Type
THT
- Type
SIP 5
- Type
Number of resistors: 4
- Resistance
2.2 kΩ
- Power rating
0.2 W
- Tolerance ±
2 %
- Temperature coefficient
100 ppm/°C
- Length
12.65 mm
- Width
2.49 mm
- Height
5.08 mm
- Content
1 pc(s)
- Dim
(L x W x H) 12.65 x 2.49 x 5.08 mm
- Type
4605X-101-222LF
- Max. temperature
125 °C
- Product type
Resistor ladder
Documents & Downloads
Datasheet
Datasheet 2996336 Bourns 4605X-101-222LF Resistor ladder 2.2 kΩ THT SIP 5 0.2 W 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2996336 Bourns 4605X-101-222LF Resistor ladder 2.2 kΩ THT SIP 5 0.2 W 1 pc(s)
Description
Resistor networks type Bourns 4600X. Thick film, SIL type (single-in-line), with resistors connected with each other (same values) and a common connection (Bussed resistors) With 4 5-pin resistors. Type 4605X-101-RC.
