Name: Busch-Jaeger Cover Busch-axcent Platinum 2CKA001754A4687 1 pc(s)
Brand: Busch-Jaeger
SKU: 3544864

A gray rectangular film strip with five empty black frames aligned vertically.

Image similar

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Busch-Jaeger cover frame platinum 1725-270

Busch & Jaeger Switch Product Range

Technical specifications

Height: 375 mm
Width 91 mm
Depth: 11 mm
Material: Metal
Colour: Platinum
Protection class (IP) IP20
Mounting width 70 mm
Mounting height 54 mm
Surface protection: Anodised/anodized
Impact strength: IK03
Transparent: No.
Design of surface: Matt
With hinged cover: No.
Halogen-free: Yes
Flush mounting: Yes
Material quality: Aluminium
Mounting method: Clamp mounting
Antibacterial treatment: No.
Number of units: 5
Mounting direction: Horizontal and vertical
Number of units horizontal: 5
Number of units vertical: 5
With mounting frame: No.
Suitable for underground passage box: No.
Suitable for device installation channel: Yes
Suitable for panel mounting: No.
Text field/label area: No.
Diameter boring (opening): 71 mm

Type: Busch-Jaeger cover frame platinum 1725-270

Product type: Faceplate

Switch type component: Cover

Type series: Busch-axcent

Factory colour: Platinum

Content: 1 pc(s)

Material: Aluminium

UKCA: not relevant

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3544864 Busch-Jaeger Cover Busch-axcent Platinum 2CKA001754A4687 1 pc(s)

Description

To cover switches, buttons and sockets.
Real metal surface
Recommendation: Protect more sensitive real materials from increased mechanical stress!
Design line: Busch-aXcent®, platform 63
Design line variant: Pure Busch-aXcent®
