Name: Circuit breakers 3-pin 1600 A 8 makers, 8 breakers 690 V AC Siemens 3KD54300RE200
Brand: Siemens
SKU: 1742341
Availability: BackOrder

A three-pole circuit breaker with a rotary knob in the centre. Silver connection terminals are arranged at the top and bottom.

Circuit diagram with two parallel connections. On the left is a resistor marked '-Q'. On the right are three vertical lines, each representing a connection from top to bottom.

Technical drawing of a box enclosure with detailed dimensions in millimetres, showing front and side views.

1/3

Image similar

Product type

Circuit breakers

Nominal voltage

690 V AC

Number of pins

Nominal current - rounded value

1600 A

Contact type

8 makers

8 breakers

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Wed 18 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 3,009.00 / piece)

€ 3,009.00

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Protection class: IP20
Isolation voltage: 1000 V
Ambient temperature: -25 °C to +70 °C
Surge voltage resistance: 12 kV
Mechanical life: 6000
Electrical life: 500
Power loss: 171 W
Design of the electrical connection: flat connector
Size of the switch disconnector: 5
Mounting type: screw fastening

Product type: Circuit breakers

Contact type: 8 makers
8 breakers

Operating voltage: 690 V AC

Nominal voltage: 690 V AC

Number of pins: 3

Dim: (W x H x D) 360 x 310 x 152.5 mm

Nominal current: 1600 A

Nominal current - rounded value: 1600 A

Type: pressure switch

Width: 360 mm

Height: 310 mm

Depth: 152.5 mm

: 8

: 8

: 1600 A

: 3

: IP00

: 0

: 1

: FALSE

: FALSE

: Flat plug-in connection

: TRUE

: None

: TRUE

: TRUE

: TRUE

: 900 kW

: 55 kA

: Other

: TRUE

: FALSE

: FALSE

: FALSE

: FALSE

: 1000 V

: FALSE

: FALSE

: Built-in device fixed built-in technique

: 1600 A

: 400 kW

: FALSE

: 1600

: Other

UKCA: yes
