Name: Circuit breakers Black 2-pin 16 mm² 32 A 800 V DC Siemens 3LD22308VQ110AF6
Brand: Siemens
SKU: 1745093
Availability: InStock

A grey electronics box with a black rotary switch at the front. Three terminal blocks are located on the top. Marked with 'Siemens'.

Technical drawing of a two-dimensional switch with dimensions in millimetres. Shows front, side, and top view.

1/2

Image similar

Product type

Circuit breakers

Nominal voltage

800 V DC

Number of pins

Nominal current - rounded value

32 A

Operating voltage

800 V DC

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Fri 6 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 204.99 / piece)

€ 204.99

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Protection class: IP40
Isolation voltage: 800 V
Operating frequency: 50/60 Hz
Ambient temperature: -25 °C to +55 °C
Surge voltage resistance: 6 kV
Mechanical life: 100000
Electrical life: 6000
Color of the actuator: black
Size of the switch disconnector: 2

Product type: Circuit breakers

Operating voltage: 800 V DC

Nominal voltage: 800 V DC

Factory colour: Black

Cross section: 16 mm²

Number of pins: 2

Dim: (W x H x D) 98 x 128 x 129 mm

Nominal current: 32 A

Nominal current - rounded value: 32 A

Type: DC switch

Width: 98 mm

Height: 128 mm

Depth: 129 mm

: 32 A

: 2

: IP40

: 1

: TRUE

: FALSE

: Frame clamp

: FALSE

: Toggle

: TRUE

: TRUE

: TRUE

: 0.64 kA

: Black

: TRUE

: FALSE

: FALSE

: TRUE

: TRUE

: FALSE

: FALSE

: Built-in device fixed built-in technique

: 32 A

: FALSE

: Other

UKCA: yes
