Conrad Components 193135 Clap on clap off Assembly kit 12 V DC
EAN:
Part number:
Item no:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 12.60
3
6% = € 0.70
€ 11.90
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 12.60 / piece)
€ 12.60
plus VAT.
Highlights & Details
Conrad Components 193135 Clap on clap off Assembly kit 12 V DC
- Build a clapper switch
- Turn 230V appliances on/off by clapping
- Includes microphone with adjustable sensitivity
Technical specifications
- 500 W
- Operating voltage
15 Vdc (max)
- Product type
Clap on clap off
- Current consumption
5A (max)
- Version
Assembly kit
- Operating voltage
12 V DC
- Dim
(L x W) 80 mm x 45 mm
- Width
45 mm
- Length
80 mm
- Output rating
500W (max)
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 193135 Conrad Components 193135 Clap on clap off Assembly kit 12 V DC
Description
Once constructed, this kit produces a clapper switch that can be used to switch 230V appliances (max 500W) such as lighting or heaters on/off by clapping. Clap once for on, clap again for off. The kit includes all necessary components including a condensor microphone and suitable relay. The sensitivity of the microphone can be adjusted via a trimpot included on the board. An LED is illuminated when the relay is active.
Features
- Protected against polarity reversal
Scope of delivery
- All necessary components to build a clapper switch
