Digitus DA-71156 M.2 SSD enclosure USB C® (USB 3.2 1st gen) 5 GBit/s M.2 PCIe NVMe 2230, 2242, 2260, 2280 DA-71156
EAN:
Part number:
Item no:
Number
Total (€ 17.64 / piece)
€ 17.64
plus VAT.
Highlights & Details
Digitus USB M.2 hard drive enclosure, SSD, external, NVMe + SATA, 10Gbps (NVMe) 6 Gbps (SATA), USB3.1 Gen2, aluminum, tool-free
- Wide compatibility: Supports M.2 modules in 2230, 2242, 2260 and 2280 formats, compatible with a wide range of SSDs.
- High capacity: Offers up to 8 TB of storage space for all your files and data.
- Fast data transfer: Data transfer rate of 10 Gbps (6Gbps in SATA) for fast file transfers and smooth performance.
- USB 3.1 Gen 2 interface: Latest USB technology with downward compatibility to USB 3.1, 3.0, 2.0 and 1.1.
- Plug and Play: Simply connect via USB and start immediately.
- Cross-platform support: Compatible with Windows, MacOS, Linux, Google Chrome OS, Android and iOS.
- Robust chipset: JMS581DL chipset for reliable and efficient performance.
- LED-activity display: Integrated LED-display for monitoring the status of your SSD.
- Long-lasting and stylish: Aluminum housing in Pantone 430C with excellent passive heat dissipation.
- Portable design: Compact and light with dimensions of 101x32x10 mm and a weight of only 97 g.
Technical specifications
- Data transfer rate: SATA: 6 Gb/s, NVMe: 10 Gb/s.
- JMS581DL chipset
- Operating temperature: +5 to 50°C
- Storage temperature: -40 to 70°C.
- Operating Humidity: 5 to 90% (Non-Condensed)
- Installation without any tools
- LED activation indicator
- Passive heat dissipation
- Supports Plug & Play
- Product type
M.2 SSD enclosure
- HDD connection
M.2 PCIe NVMe
- Compatible with
2230
2242
2260
2280
- Supported HDD size (max.)
8 TB
- Max. hard drive height
3.5 mm
- Interfaces
USB C® (USB 3.2 1st gen)
- Transfer rate
5 GBit/s
- Power supply (LOV)
via USB
- Storage media features
M.2 slot
NVMe support
- Material
Aluminium
- Factory colour
Grey
- Width
101 mm
- Height
10 mm
- Depth
32 mm
- Dim
(W x H x D) 101 x 10 x 32 mm
- Weight
97 g
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3306748 Digitus DA-71156 M.2 SSD enclosure USB C® (USB 3.2 1st gen) 5 GBit/s M.2 PCIe NVMe 2230, 2242, 2260, 2280 DA-71156
Description
The DA-71156 USB hard disc casing offers a versatile and powerful storage solution for both NVMe SSD and SATA SSDs. It is compatible with a wide range of SSDs with support for M.2 modules in 2230, 2242, 2260 and 2280 formats as well as a maximum storage capacity of up to 8 TB. The data transfer rate is 10 Gbps for NVMe and 6 Gbps for SATA, while the USB 3.1 2nd Gen interface is backwards-compatible with USB 3.1, 3.0, 2.0 and 1.1. Tool-free design makes installation easy, and the robust JMS581DL chipset ensures reliable and efficient performance. An integrated LED-display simplifies the monitoring of the SSD-status, and the long-life aluminum casing in Pantone 430C offers excellent passive heat dissipation. With compact dimensions of 101x32x10 mm and a weight of only 97 g the housing Ideal is for mobile usage. It supports Plug and Play and is powered directly via the USB port. The housing is compatible with Windows (11, 10, 8, 7, XP, 2000), MacOS, Linux (2.4.x or higher), Google Chrome OS (9.x or higher), Android and iOS and provides full support for USB-C products.
This text is machine translated.
This text is machine translated.
Scope of delivery
- USB cable (C - A) - 25 cm
- Quick start guide
System requirements
- Windows 11, 10, 8, 7 or higher
- Android
- iOS
- MacOS 2.4.x or higher
- Linux 2.4.x or higher
- Google chrome OS 9.x or higher
- Free USB connection
