Buy Digitus DN-10-09U 10" wall cabinet 9 U Grey-white (RAL 7035)

An open, empty grey network distribution cabinet with a glass door, suitable for housing servers and network equipment.

Metal cabinet with an open door, showing empty interior. Suitable for storage or electronic assembly.

Isolated white plastic container with a transparent door window, secured by a metal latch. Used for secure storage.

An open network rack cabinet with multiple connected blue Ethernet cables, patch panels, and network devices.

Ethernet switch with blue network cables plugged in and connected to ports, showing network cabling in a server room.

A network server rack with multiple blue Ethernet cables plugged into numbered ports. Cables are neatly organised.

Metal electrical cabinet opened, showing empty interior with mounting brackets for technical equipment. Door on the left with lock and hinges.

1/7

28 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 67.22 / piece)

€

Report legal concerns

Highlights & Details

Digitus 254 mm (10") 9HE Wall housing 464x312x300 mm, color gray (RAL 7035)

Protection class: IP20
Lockable safety glass door
200° door opening angle
1-point locking on the front door
254 mm (10") profile rails mounted on the front inside the cabinet, galvanized
254 mm (10") profile rails are adjustable in depth
1.1 - 1.5 strong sheet steel with a high load capacity, powder-coated
Cable input with brush strip in the roof and with plastic cover in the floor
Ventilation slots for active and passive ventilation
Installation depth for components max. 240 mm
IP protection class IP20
Color: Light gray, RAL 7035
Depth: 300 mm
Front door: Glass door, single-wing
HE: 9
Carry load: 30 kg
Mounted: Yes
Cabinet type: Wall housing
Width 312 mm

Technical specifications

Factory colour: Grey-white (RAL 7035)

Depth: 300 mm

Height: 464 mm

Width: 312 mm

Rack unit: 9 U

Material: Steel
Safety glass

Wireless charging: No

Weight: 7.400

Product type: 10" wall cabinet

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 1881754 Digitus DN-10-09U 10" wall cabinet 9 U Grey-white (RAL 7035)

Description

Digitus

The small 10" network wall housing stands out with its compact dimensions at full suitability for structured IT cabling - ideal for home or small office environments

A lockable glass door protects the office or home network from unauthorized access, yet still enables the visual control of Internet router, NAS server or network switch

Optimal integration in the house cabling - through the cable entries in the floor and roof power and network cables can be inserted from below as well as from above into the mini-rack

The profile rails can be attached in 2 different positions - the steel housing can be connected via the earthing bolt with the equipotential bonding of the house cabling

Various IT components such as patch panels, LAN & PoE switches, socket strips as well as cable management solutions and shelves from Digitus are available for the 10-inch form factor (254 mm)

The 254 mm (10”) wall housings are made of a robust steel construction. The cable entry openings in the roof and floor offer the best possibilities for a proper cable management. The compact housing is therefore ideal for all common IT and telecommunications applications, especially in limited space and private households.

This text is machine translated.
