Name: Diotec Schottky diode SB560-3G DO 201 60 V Schottky
Brand: Diotec
SKU: 2810537
Availability: InStock

Two black diodes are positioned diagonally and parallel to each other on a white background. They have silver connections at both ends.

Image similar

Product type

Schottky diode

Enclosure

DO 201

Reverse voltage U(R)

60 V

Forward current I(F)

5 A

Configuration (diode)

Schottky

Datasheet (PDF)

Dispatches on Thu 22 Oct

1700 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 90

Total (€ 0.25984 / piece)

€ 23.39

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Type: SB560-3G

Product type: Schottky diode

Enclosure: DO 201

Manufacturer: Diotec

Manuf. code: DIO

Reverse voltage U(R): 60 V

Forward current I(F): 5 A

Reverse leakage current I(r): 50 µA

Configuration (diode): Schottky

Peak forward surge current I(FSM): 125 A

Forward voltage U(F): 0.55 V

Forward voltage reference: 5.00 A

Reverse leakage current I(r) reference: 60 V

Diode capacitance C(D): 250 pF

Operating temperature (max.): 150 °C

Mounting type: Through-hole mounting

RoHS-compliant: Yes

Content: 1 pc(s)

UKCA: yes
