Diotec Schottky diode SMS540-3G DO 213AB 40 V Schottky
EAN:
Part number:
Item no:
Product type
Schottky diode
Enclosure
DO 213AB
Reverse voltage U(R)
40 V
Forward current I(F)
5 A
Configuration (diode)
Schottky
Datasheet (PDF)
Number
Total (€ 0.09 / piece)
€ 0.09
incl. VAT
14-day return policy included
Highlights & Details
Schottky, Melf, 40V, 5A
Our service for you
Technical specifications
- Type SMDHousing DO-213AB/MelfPeriodic Peak Reverse Voltage - VRRM 40 VContinuous current - IFAV 5.00 AJunction temperature - Tjmax 150 °CForward voltage - VF 0.50 VIF 5.00 ASurge current - IFSM 80.00 AReverse current - IR 90,000 µAVR 40 VLock layer capacity - CJ 220 pFVR 4 V
- Type
SMS540-3G
- Product type
Schottky diode
- Enclosure
DO 213AB
- Manufacturer
Diotec
- Manuf. code
DIO
- Reverse voltage U(R)
40 V
- Forward current I(F)
5 A
- Reverse leakage current I(r)
90 µA
- Configuration (diode)
Schottky
- Peak forward surge current I(FSM)
80 A
- Forward voltage U(F)
0.50 V
- Forward voltage reference
5.00 A
- Reverse leakage current I(r) reference
40 V
- Diode capacitance C(D)
220 pF
- Operating temperature (max.)
150 °C
- Mounting type
Surface-mount
- RoHS-compliant
Yes
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 2810894 Diotec Schottky diode SMS540-3G DO 213AB 40 V Schottky
User & Safety Instructions
User & Safety Instructions 2810894 Diotec Schottky diode SMS540-3G DO 213AB 40 V Schottky
