Name: Eaton DILMP125(RDC24) Electrical contactor 125 A Compatible with (relay brand): Eaton 1 pc(s)
Brand: Eaton
SKU: 3193561
Availability: BackOrder

Product type

Electrical contactor

No. of pins

4-pin

Current load

125 A

Connection

Screws

Type

DILMP125(RDC24)

Datasheet (PDF)

Dispatches on Fri 23 Oct

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 609.00 / piece)

€ 609.00

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Product type: Electrical contactor

Type: DILMP125(RDC24)

No. of pins: 4-pin

Control voltage (min.): 24 V DC

Control voltage (max.): 27 V DC

Control voltage range: 24 - 27 V DC

Permanent current (max.): 125 A

Current load: 125 A

Compatible with: Eaton

Connection: Screws

Durability: 10000000

: IP00

Min. temperature: -25 °C

Max. temperature: +60 °C

Width: 122 mm

Height: 170 mm

Depth: 160 mm

Dim: (W x H x D) 122 x 170 x 160 mm

Content: 1 pc(s)

RoHS-compliant: Yes

: 122 mm

: 170 mm

: 160 mm

: FALSE

: 37 kW

: 4

: 0

: 0

: 0

: 80 A

: 125 A

: 0-0 V

: 0-0 V

: 24-27 V

: Screw connection

: 230-690 V

: 230-690 V

: DC

: 115 A

: 28 kW

: 44.7 kW

UKCA: yes
