Name: Eaton EP-501041 SPZT123-300/3+NPE-S-OS Surge arrester Surge protection for: 40 mm busbar 7.5 kA 1 pc(s)
Brand: Eaton
SKU: 2734687
Availability: BackOrder

An Eaton electrical circuit breaker for circuit protection, vertically mounted, white housing with labelling.

'Slim, grey Eaton circuit breaker with blue labelling and symbols. Suitable for 400VAC. CE and UL certification marks.'

1/3

Datasheet (PDF)

Dispatches on Thu 29 Oct

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 174.99 / piece)

€ 174.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Surge arrester for 40-mm busbar, TN-S/TT, 3P, 7.5 kA (10/350)µs, class I+II+III/type 1+2+3

Easy Implementation7.5kA with voltage pickupEnergetic coordinated protection effect to the terminalVoltage-switching spark-distance technology

Technical specifications

Mains type TNMAINS TYPE TN-C-SMains form TN-SMains form TTNumber of pins: 4Surge current (10/350 µs) 7.5 kAMaximum continuous voltage AC 300 VNominal voltage AC 240 VProtection level 1.5 kVProtection level L-N 1.5 kVProtection level N-PE 1.5 kVSuppression load 0.1 kASpecific energy (W/R): 14 kJ/ohmMax. Overcurrent protection device Stitch wiring (fuse): 160 A.Busbar mountingInstallation size 2 TESignalling at device: OpticalTest class: Type 1 and 2 and 3

Product type: Surge arrester

Surge protection for: 40 mm busbar

Leakage current: 7.5 kA

Nominal voltage: 240 V AC
300 V AC

: IP20

Manufacturer part #: EP-501041

Type: SPZT123-300/3+NPE-S-OS

Factory colour: Light grey

Standards: VDE 0100-443/-534Class I+II+III/type 1+2+3IEC 61643-11 2011EN 61643-11: 2012+A11: 2018Lightning protection class III and IV according to IEC 62305, fault current free

Dim: (W x H x D) 38 x 233.4 x 102.3 mm

Width: 38 mm

Height: 233.4 mm

Depth: 102.3 mm

Content: 1 pc(s)

Number of pins: 4

Weight: 680 g

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2734687 Eaton EP-501041 SPZT123-300/3+NPE-S-OS Surge arrester Surge protection for: 40 mm busbar 7.5 kA 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2734687 Eaton EP-501041 SPZT123-300/3+NPE-S-OS Surge arrester Surge protection for: 40 mm busbar 7.5 kA 1 pc(s)

Description

The overvoltage protection SPZT123 of Eaton is especially meant for installations in buildings according to VDE 0100-443/-534. The installation is done pluggable on the 40 mm-conductor rail of the meter distributor in the network-side connection area in the network-side connection area (NAR). Neither screws nor tools are required for installation. A corresponding housing design prevents the wrong positioning and automatically adjusts to the 5 mm or 10 mm busbar

This text is machine translated.

Features

Easy Implementation7.5kA with voltage pickupEnergetic coordinated protection effect to the terminalVoltage-switching spark-distance technologyTo protect consumer systems against transient surges caused by direct and indirect lightning strikes, as well as switching operationsLightning protection class III and IV according to IEC 62305Fulfils all requirements for the installation of overvoltage protection according to DIN VDE 0100-534For TT & TN-S grid forms
