Name: Eberle 0524 72 141 894 UTR-60 Universal thermostat Surface-mount UTR 60 1 pc(s)
Brand: Eberle
SKU: 613112
Availability: InStock

Highlights & Details

Universal temperature regulator UTR

IP65

Technical specifications

Permissible ambience temperature: -20 to +50 °C
Cable entry 2 x M 16.1 x PG 16

Product type: Universal thermostat

Operation type: mechanical

Max. temperature setting: 60 °C

Temperature settings: 0 up to 60 °C

Frost protection: No

Display: No

Remote sensor: Optional

Compatible with: Multi-purpose use

Mounting type: Surface-mount

Power supply (LOV): mains-powered

Operating voltage: 230 V

Hysteresis: 0.5 to 5 °C (up to 100 °C), 0.5 to 10 °C (from 100 °C)

Contact load capacity: 3680 W

Contact current: 16 A

Nighttime drop: Yes

Factory colour: Grey

Width: 7 cm

Height: 55 mm

Length: 3.6 cm

: IP65

Dim: (L x W x H) 3.6 cm x 7 cm x 55 mm

Type: UTR 60

Weight: 440 g

Contact type: 1 change-over

Min. temperature setting: 0 °C

Adjustment range: 0 - 60 °C

Operating voltage: 230 V/50 Hz

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 613112 Eberle 0524 72 141 894 UTR-60 Universal thermostat Surface-mount UTR 60 1 pc(s)

Conformity certificate

Conformity certificate 613112 Eberle 0524 72 141 894 UTR-60 Universal thermostat Surface-mount UTR 60 1 pc(s)

Description

For universal use, for example, for direct floor, floor space, open space heating, pool control, air conditioning systems. The device is suitable for heating and cooling functions, and features an adjustable hysteresis of 0.5 to 10 K. A temporary reduction in temperature (forexample, night drop) by 5 K can be realized by a connection of a timer switch on the potential-free contacts. A green LED indicates when the relay has attracted, a red LED indicates a probe break.

Scope of delivery

Universal temperature regulator User manual.
